Our neodymium Rod magnets are built for collecting & eliminating minor ferromagnetic debris & unwanted ferrous metals & fragments from products that flow freely. They are perfect for cleaning or eliminating tramp metals in sensitive industrial processes or food processing equipment.
Simple to use & easy to install, they can be used on their own or incorporated into grates or grids.
1. A magnetic rod is an effective filtering system with plenty of applications, made with Neodymium (NdFeB) Rare Earth magnets arranged in opposition. Magnetic rod is a convenient filter with a wide variety of applications.
2. It is organized in repulsion and held in a 304 or 316 stainless steel case that is welded, cleaned, and polished to be watertight so that no liquid, fine powder, or gas can penetrate the interior.
3. This makes it impermeable, so liquids, fine powder, or gases cannot penetrate its interior.
4. A magnetic rod is utilized to adsorb external ferromagnetic particles to extract iron and protect the equipment that follows. It is used to attract external ferromagnetic particles to extract iron and safeguard the equipment.
Specifications:
| Materials: | 304 and 316 Stainless Steel + NdFeb Magnets |
| Shape: | Bar, Rod, Tube, Grill |
| Standard diameter: | D19, D22, D25, D32 |
| Length: | 50mm-500mm, up to 1000mm. Accept custom make to size |
| Surface gauss level: | 5000-12000Gs, peak Gauss read over 12000Gs |
| Max working temperature: | ≤ 300°C if need |
| Various designs of the end: | Sealed, drilled, tapped holes, with bolt, or as your request |
| Packaging: | Wooden Carton + Shielding for Air shipment |
Production Flow
Product Display:
Magnetic Rod with Argon arc welding head
Magnetic Rod with Internal Thread
Magnetic Rod with External Thread
Magnetic Rod with Ring End
Magnetic Rod with Handle
Magnetic Rod with Custom Cone Ends
Our Advantages:
Applications: Medicine, Food, Chemicals, Plastics, Ceramics, Tobacco, Glass, and other Industries.
Packing & Delivery:
Typically magnets with a net weight below 100KGS, we suggest shipping via Air/Express, whereas if the net weight is around or over 100JGS, then Sea freight is suggested as a more cost-effective way of shipment.
Why Honsen Magnetics
Our complete production line guarantees production capacity from raw materials to finished products
We serve ONE-STOP-SOLUTION to ensure customers efficient and cost-effective purchasing.
We test each piece of magnets to avoid any quality problem for customers.
We offer different types of packaging for customers to keep products & transportation safe.
We work with big customers as well as small ones without MOQ.
We offer all kinds of payment methods to facilitate customers' purchasing habits.
